Tech Specs at a Glance:Magnification: 10xObjective Size: 42 mmTotal Weight: 924 g / 32.6 ozDimensions (H / W / L): 3.1" / 5.3" / 6.6"Exit Pupil: 4.2 mmField of View: 6.8 DegreesMeasurement Range: 10 - 2200 ydsBallistic Output: Yes
SPECIFICATIONS
EL 10x42 Range
Magnification
10x
Objective Lens Diameter
42 mm
Exit pupil diameter (mm)
4.2
Exit pupil distance (eye relief) (mm)
19
Field of view (ft/1000 yds)
359
Field of view (degrees)
6.8
Shortest focusing distance (ft / m)
16.4 / 5
Light transmission (%)
Dioptric compensation (dpt)
- /+ 5
Length approx. (in / mm)
6.6 / 160
Width approx. (in / mm)
Height approx. (in / mm)
3.1 / 81
Weight approx. (oz / g)
32.6 / 924
Battery type
CR2
Measurement Specs
Range
10 - 2200 yds
Accuracy
+/- 1 yd
Measuring Time
< .5 seconds
Angular Measurement
+/- 90 Degree
Laser type
Class 1 EN/FDA
Units
Meter / Yards
Battery Life Cycle
2000 Measurements
